  • ODC Fiber Optic Patch Cord / fiber cable with ODC-2 ,ODC-4, LC connector

    Connector typeDLC/UPC
    Insertion Loss<=0.3db
    Return Loss>=35db
    Fiber modeMulti-mode,50/125,single mode,9/125
    Operating wavelength850nm, 1300nm,1310,1550nm
    Test wavelength850nm, 1300nm
    Repeatability<=0.1
    Interchangeability<=0.2dB
    Durability<=0.2dB
    Fiber Length1m~150m
    enquiry
    • Specifications

    ODC Fiber Optic Patch Cord / fiber cable with ODC-2 ,ODC-4, LC connector

    ODC Fiber Optic Patch Cord is made of the ODC Connector together with the far transmission cable, are becoming the standard interface specified in 3G, 4G and Wimax Base Station remote radios and FTTA (Fiber-to-the-Antenna) applications.

    The ODC Cable assemblies have passed testes like salt mist, vibration and shock and meet protection class IP67. They are well suited for Industrial and Aerospace and Defense applications.

    Feature of ODC Fiber Optic Patch Cord:

    • Screwed locking mechanism, confirm the connection is long-term and reliable.
    • Guide structure, can be installed blindly, simply and quickly.
    • Airtight construction: Water proof, dust proof and corrosion resistant. Protection caps.
    • Compact appearance, robust and flexible.
    • Sealing design through wall.
    • Reduce the times of splicing.

    ODC Fiber Optic Patch Cord Application

    • Indoor and Outdoor applications
    • Outdoor & Military communication equipment connection.
    • Oil field, mine communication connection.
    • Far transmission wireless base station.
    • Optical fiber sensor.
    • Railway signal control.
    • Intelligent substation

    Parameter of ODC Fiber Optic Patch Cord

    Insertion Loss<=0.8dB
    Repeatability<=0.5dB
    Fiber Core2
    Mating times>=500N
    Working temperature-40 ~ +85℃

    ODC- LC Fiber optical Patch Cord

    Fiber Specification:
    Fiber type
    50/125,9/125
    Core Diameter
    50 + 2.5
    Core Non-Circularity
    <=5.0 %
    Cladding Diameter
    125.0+1.0um
    Cladding Non-Circularity
    <=1.0 %
    Coating Diameter
    245+7
    Coating-Cladding Concentricity Error
    <=12.0um
    Coating Non-Circularity
    <=6.0um

    .

    Connecton Specification
    ITEM
    PARAMETER
    Connector type
    DLC/UPC
    Insertion Loss
    <=0.3db
    Return Loss
    >=35db
    Fiber mode
    Multi-mode,50/125,single mode,9/125
    Operating wavelength
    850nm, 1300nm,1310,1550nm
    Test wavelength
    850nm, 1300nm
    Repeatability
    <=0.1
    Interchangeability
    <=0.2dB
    Durability
    <=0.2dB
    Fiber Length
    1m, 2m….. any length optional.
    Length and tolerance
    10cm
    Operating Temperature
    -40C ~ +85C
    Storage Temperature
    -40C ~ +85C

    Specification
    Standard Duplex LC connector, well connected with standard LC adaptor
    Available Single mode and Multimode
    IP67 protection, salt-mist proof, humidity proof, dust proof
    Low insertion/return loss, steady optical transmitting.
    Light weight, waterproof, dustproof, moisture proof, Metal hard housing.

    Usage

    Widely used in FTTA & FTTH
    Used for 3G 4G 5G base station
    BBU, RRU, RRH Application

    ODC LC 11 scaled - ODC Fiber Optic Patch Cord / fiber cable with ODC-2 ,ODC-4, LC connector

    ODC fiber cable 26 - ODC Fiber Optic Patch Cord / fiber cable with ODC-2 ,ODC-4, LC connector

    ODC LC 8 scaled - ODC Fiber Optic Patch Cord / fiber cable with ODC-2 ,ODC-4, LC connector

    20200923100413 scaled - ODC Fiber Optic Patch Cord / fiber cable with ODC-2 ,ODC-4, LC connector
